Thước đo cao Trimos V3-400
Trimos High Gauge V3
|
V3 |
|
400 |
700 |
|
Measuring range |
mm (in) |
407 (16) |
711 (28) |
|
Measuring range with extension |
mm (in) |
508 (20) |
812 (32) |
|
Max permissible errors |
µm |
|
|
Repeatability (2s) |
µm |
2 (Ø: 4) |
|
Frontal squareness deviation |
µm |
10 |
15 |
|
Resolutions |
mm |
0.001 |
|
Measuring force |
N |
0.75 ÷ 1.5 |
|
Autonomy |
h |
40 |
|
Interfaces |
|
USB / RS232 |
|
Air cushion |
|
No |
|
Weight |
kg |
21 |
24
|
